Number of Channels:8
Isolation Type:Opto-isolated
Relay Type:SPST
Operating Voltage:DC 12V to 28V
Current Rating per Channel:5A @ 24VDC
Input Voltage Range:0V to 30VDC
Operating Temperature Range:-40°C to +70°C
Package Size:45mm x 34mm x 16mm
Operating Current:≤ 100mA at 50mA/channel
Relay Contact Rating:250Vac/30Vdc
Mounting:Panel mount
Operating Humidity:0% to 95% non-condensing
Certifications:CE, UL, CSA
Introducing the Moxa 5094-OW8I, a high-performance 8-point isolated relay output module tailored for industrial automation environments. This module ensures robust and reliable control signals, facilitating smooth operation in challenging conditions.
Featuring electro-mechanical isolation, the Moxa 5094-OW8I guarantees enhanced safety by separating power and signal paths. Each relay is rated for 5A at 24VDC, providing ample capacity for demanding applications.
With support for operating voltages from 12V to 48V DC and a current rating of 0.2A per channel, this module caters to a wide range of devices. The SPST (Single Pole, Single Throw) relay contacts ensure precise switching actions.
Operating within a temperature range of -40°C to +70°C and capable of withstanding storage temperatures up to +85°C, the Moxa 5094-OW8I is built to withstand extreme conditions. Its RS-485 interface offers versatile communication options with adjustable data rates from 1200bps to 9600bps.
Efficient power consumption of 1.5W ensures minimal energy use, contributing to cost-effective and eco-friendly operations. Compact dimensions of 86mm x 48mm x 22mm and a lightweight design of 65g make installation straightforward and space-efficient.
